UC2000-VF
GSM VoIP Gateway
GSM VoIP Gateway
UC2000-VF is a 16-channel GSM/3G/4G Gateway in 1U field-proven hardware
design, used to establish connections between mobile and VoIP networks, for
transmission of both voice and SMS. Integrated GSM/WCDMA/LTE connectivity and
SIP protocol compatible with mainstream VoIP platforms, it is suitable for
enterprises, multi-site organizations, call terminators and areas with limited
landline like rural area to cut down telephony costs and enable easy & efficient
communications.
It works standalone and also supports remote SIMs management as an option with
youxi SIMBank and SIMCloud.
-
VoLTE -
Voice -
SMS -
API -
SIP -
SIMCloud
Detailed parameters
-
1 SIM slot, 1 antenna
-
GSM: 850/900/1800/1900MHz
-
SIP v2.0, RFC3261
-
Codecs: G.711A/U , G.723.1, G.729AB
-
Echo Cancellation
-
DTMF: RFC2833, SIP Info
-
Mobile to VoIP, VoIP to Mobile
-
SIP Trunk and Trunk Group
-
Port and Port Group
-
Caller/Called Number Manipulation
-
SIP Codes Mapping
-
White/Black List
-
PSTN/VoIP Hotline
-
Abnormal Call Monitor
-
Call Minutes Limitation
-
Balance Check
-
Random Call Interval
-
API
-
Polarity Reversal
-
PIN Management
-
SMS/USSD
-
SMS to Email, Email to SMS
-
Call Waiting/Call Back
-
Call Forward
-
GSM Audio Coding: HR, FR,EFR, AMR_FR,AMR_HR
-
HTTPS/HTTP Web Configuration
-
Configure Backup/Restore
-
Firmware Upgrade by HTTP/TFTP
-
CDR(10000 Lines Storage Locally)
-
Syslog/Filelog
-
Traffic statistics: TCP,UDP,RTP
-
VoIP Call Statistics
-
PSTN Call statistics: ASR,ACD,PDD
-
IVR Customization
-
Auto Provisioning
-
SIP/RTP/PCM Capture
